TC-100 Tablet Controller

The Wachs TC-100 Tablet Controller is a new way of controlling your valve maintenance systems, offering the same portability as the previous handheld but built on a new, more powerful architecture. Featuring the latest version of VITALS Mobile TC Software running on Windows 10, it offers enhanced compatibility with your desktop system. Meeting IP68 and MIL-STD-810G ratings, its rugged ergonomic design and long battery life means it’s able to handle a long day on the job in the harshest environments.

Wachs TC-100 features a Quad-core Pentium N4200 processor for faster operation, and increased storage capacity for future upgradeability. Standard with 8GB ram memory and 128GB flash storage, it offers additional removable storage via a Micro SDXC card slot. Wachs TC-100 utilizes Microsoft’s Windows 10 Pro operating system, designed to handle larger files and detailed maps. A docking station / charging cradle that allows for easy charging and quick desktop connections is a recommended option. It includes a RJ45 Ethernet connection, plus USB and HDMI ports for connecting an external monitor, keyboard, mouse and more.

Wachs TC-100 dust and water resistant ergonomic enclosure includes a sunlight-readable display, and a 43.2 Watt-hour battery will power you through the day. Should it run low, the included AC and vehicle chargers allow you to top off anywhere. Designed and assembled in the United States, the TC-100 offers superior build quality and secure data protection. The TC-100 is supported by Wachs Utility Products US based customer service, and includes a full one-year warranty against manufacturer defects, with a three year plan optionally available.

The Wachs TC-100 is sold in a kit which includes:

Removable Li-Ion battery
Hand strap
Standard stylus and tether
Wet conditions stylus and tether
AC wall charger
TC 100 vehicle charger
Wachs control cable assembly

Details

Product Specifications

TC-100 WINDOWS 10
Microsoft Windows 10 Pro
Quad-core Intel Pentium N4200 processor
Intel HD Graphics
8 GB LPDDR4 Memory 128 GB Flash Storage
Micro SDXC card slot

WIRELESS CONNECTIVITY
Long-range Bluetooth Smart Ready wireless technology, v5.0 + EDR, Class 1.5, BLE support
Wi-Fi 802.11 a/b/g/n/ac, 2.4 GHz and 5 GHz
2×2 MIMO antenna

DISPLAY
Active viewing area: 7″ (178 mm)
Resolution: WXGA (1280 x 800)
High-visibility backlit LCD for best-in-class sunlight view-ability
Portrait or landscape orientation with automatic screen rotation
Ambient light sensor

TOUCHSCREEN
Capacitive multi-touch interface for use with gloves, small tip stylus, and in wet conditions
Optically bonded for increased visibility and strength
Chemically-strengthened Dragontrail™ High Ion-Exchange (HIE™) glass, impact and scratch resistant
Multi language support for English, French, Spanish, German, and Portuguese

KEYPAD
Adjustable LED backlit keys
Four-way directional navigation pad
Windows/home key
Power key, Enter key
Three user-programmable function keys

RUGGEDISED CONSTRUCTION
IP68 waterproof & dustproof – Water: 1.4 m (4′ 7″) for 2 hours
Operating temperature: -4 F to 122 F (-20 C to 50 C)
Storage temperature: -22 F to 158 F (-30 C to 70 C)
Shockproof: multiple drops from 4′ (1.2 –1.5 m) onto concrete

PORTS
12V DC power input jack
USB 3.0 x 1
3.5 mm audio jack output
Docking connector (Power, USB 2.0, HDMI, & Ethernet)
Loud output speaker for noisy environments
Dual digital microphone input

BATTERY
Removable Li-Ion battery, 43.2 Watt Hours
Operates up to 15 hours on a single charge
Removable battery, easily changeable in the field
Optimized for strong performance in cold temperatures

PHYSICAL
Size: 5.4in W x 8.48in L x 1.36in D (137 x 215 x 35 mm)
Weight: 1.7 lbs. (770 g)
Durable, chemical- and shock-resistant design
Easy-to-grip, impact-absorbing, overmolded bumpers
Lightweight and ergonomic design

STANDARD ACCESSORIES
Standard 43.2 Watt-hour removable battery
AC wall charger with international plug kit
12VDC vehicle charger
Valve exerciser control cable
Capacitive small-tip stylus w/tether
Connector port dust cover
Hand strap kit
Quick Start Guide

OPTIONAL ACCESSORIES
TC-100 Office Docking Station Ethernet/HDMI/USB
TC-100 Machine Mounted Cradle
Replacement Vehicle 12VDC Charger
Replacement / Spare Rechargeable Battery
Replacement Valve Exerciser Control Cable
Extended Warranty 3 Year Protection Plan

OPERATING DIMENSIONS
137mm wide
215mm long
34mm deep

OPERATING WEIGHT
770 grams

WARRANTY
1 Year Limited Warranty
